A E Yates

Cranfield Road, Lostock Industrial
Estate Bolton, Lancashire BL6 4SB

T: 01204 696175
F: 01204 669008
E-Mail:micro@aeyates.co.uk
Website:www.aeyates.co.uk



Contact:John Nuttall / Neil McLeod

A E Yates is a progressive construction company, operating throughout the UK, Ireland and mainland Europe on both main contract and sub-contract works for a variety of clients and has evolved into a construction group with a specialist trenchless division.

The company has invested both in state-of-the-art technology and people to manage, operate and maintain this technology. Clients can be offered a range of trenchless techniques, including mechanised pipe jacking, microtunnelling, conventional tunnelling, guided auger boring and horizontal directional drilling.

The company owns and operates Iseki Unclemole, Herrenknecht, Akkerman and Soltau RVS microtunnelling and Pipejacking systems that can install a range of pipe diameters between 600mm and 1800mm. As well as Vermeer Navigator and Wirth Powerbore HDD Rigs between 12 and 70 Tonne pull-back capacity.

A E Yates provides advice and guidance on the feasibility and suitability of pipejacking and microtunnelling systems for both Design and Construction, and traditional forms of contract. A E Yates operates a quality system to ISO 9001/2000 accredited by BSI.


BACK TO TOP

Barhale PLC

Barhale House
Bescot Crescent, Walsall
West Midlands WS1 4NN

Tel: 01922 707700
Fax: 01922 721808
E-Mail:graeme.monteith@barhale.co.uk
Website:www.barhale.co.uk



Contact:Contact: Graeme Monteith Engineering Manager (Tunnelling)

Barhale plc is one of the country's leading and civil engineering and infrastructure service contractors, with an annual turnover of circa £ 130 million. The company operates throughout the UK undertaking works within all sectors of civil engineering and utilities. Its head office is in Walsall, with regional offices in Peterborough, Watford, Haydock and Glasgow. Barhale’s tunneling team has extensive experience in all forms of tunnelling and shaft sinking, as well as vast experience in micro-tunneling and slurry separation along with traditional pipe-jacks, segmental tunnels and timbered headings in all ground conditions.

Barhale undertake a wide range of tunneling projects and own and operate the following machines:

3 - Iseki Unclemole TCC 780's (600mmID); an Iseki Unclemole TCC 1400 (1200mmID); an Iseki Unclemole TCC 1800 (1500mmID) An open-faced Akkerman WM 1200S TBM (1000mmID) and an Akkerman WM 1430S TBM (1200mmID).Akkerman WM 1800s TBM (1500mmID)

The company prides itself on its professional engineering expertise, and offers clients an advisory service during the design and feasibility stages of any scheme.

Barhale Construction Services (BCS), a business unit within Barhale plc, provides a traditional plant & tool hire service to both internal and external customers. An integral part of BCS is a structural and general steel fabrication business that manufactures specialist tunnelling and pipe jacking equipment such as shields, inter-jacks, jacking rigs, tunnel eye portals, skips and bogeys, as well bespoke access platforms and bridge structures. BCS also operates a sign making service for internal and external customers. Barhale gained the "Investors in People" standard in December 2001.

As an "Investor in People" Barhale ensures that all their staff are fully trained in the skills they will need to successfully carry out their roles in delivering added-value project services to their clients whilst extending their personal development.

In October 2003 Barhale were one of the first UK companies to achieve triple certification to OHSAS 18001: 1999, BSEN ISO 14001: 1996 and BSEN ISO 9001-2000.

Barhale are also members of the Achilles Verify scheme and have undergone additional audits of its Health & Safety, Environmental and Quality management systems.

Barhale's commitment to provide value to its customers is demonstrated by award winning projects recognised by our clients and nationally recognised bodies such as the Institute of Civil Engineers (ICE), United Kingdom Society for Trenchless Technology (UKSTT), Considerate Constructors Scheme and, CEEQUAL.


BACK TO TOP

Morgan Sindall Construction Infrrastructure

Head Office
Corporation Street
Rugby CV21 2DW

Tel: 01788 534500
E-Mail:info.tunnelling@morgansindall.com
Website:https://construction.morgansindall.com



Contact:Bob Buchanan bob.buchanan@morgansindall.com

Morgan Sindall is a UK construction, infrastructure and design business with a network of local offices. The company works for private and public sector customers on projects and frameworks from £50,000 to over £1 billion. Activities range from small works and repair and maintenance, to the design and delivery of complex construction and engineering projects where it is able to provide specialist design, tunnelling, utilities, building, civil engineering and mechanical and electrical services. The company operates across the commercial, defence, education, energy, healthcare, industrial, leisure, retail, transport and water markets. Morgan Sindall is part of Morgan Sindall Group plc, a leading UK construction and regeneration group with revenue of over £2 billion and which operates through five divisions of construction and infrastructure, fit out, affordable housing, urban regeneration and investments.

Few companies can claim our accumulated experience in underground construction and whilst we are proud of our achievements of the past, our culture is one of innovation and development. We specialise in all types of tunnelling design and construction with extensive experience on major schemes comprising both hard and soft ground. An active planning, research and design facility provides in-depth capability and innovative designs for temporary and permanent works.

Our plant holding has the largest fleet of TBMs and specialist equipment within the United Kingdom, maintained at the divisions own workshops in Swynnerton. This includes full face earth pressure balance machines, roadheader and backhoe shields, locomotives, rolling stock, compressed air equipment, ventilation systems, grouting equipment, tunnel services, heavy cranes and a full range of pipejacking equipment, including slurry microtunnelling machines.

In addition to the above we have a state of the art pre-cast manufacturing facility, with automated twin carousels and batching systems. The factory was developed on a 13 acre brownfield site at Ridham Dock in Kent.


BACK TO TOP

Terra Solutions Limited

3 Carnbane Business Park
Newry, Co. Down BT35 6QH
Tel: +44(0)28 3026 9848
3 The Malthouse, Main Street
Castlebellingham
Co. Louth, Rep. of Ireland
Tel: +353(0)42-6821591
17 Chantry Lane
Hatfield, Hertfordshire AL10 9HS
Tel: +44(0)1707-268236
E-Mail:info@terrasolutions.co.uk
Website:www.terrasolutions.co.uk



Contact:

Terra Solutions are a dedicated, specialist subterranean civil engineering team providing trenchless solutions across all utility and infrastructure sectors. Our experience in Micro Tunnelling, Shaft Sinking, Open Face Pipe Jacking, Auger Boring and Horizontal Directional Drilling gives you the edge when competing in the these sectors, allowing you to proceed confidently and competitively knowing you have an experienced and reliable partner who can deliver projects effectively, efficiently and within budget. We have one of the most comprehensive fleets of trenchless equipment in the UK and Ireland including tunnel boring machines, backacters, auger boring machines and HDD units. Our complete range of ancillary and welfare equipment allows us to work quickly and efficiently with minimal assistance and main contractor attendance. Additionally, our slurry separation and flocculation systems allows us to maintain tunnelling efficiency throughout most ground conditions and reduces the environmental impact through increased efficiencies in water utilisation. With over thirty years experience in all fields of utilities, we fully understand our corporate responsibility and our works are carried out to the highest possible standards. To safeguard our team, our clients and the environment we back this up with external accreditations such as ISO9001, ISO14001, ISO 18001 and Safe T Cert health & safety system. Our membership of industry organisations such as the Pipejacking Association, British Tunnelling Society and the United Kingdom Society for Trenchless Technology ensures we remain informed of and involved in industry best practice. We pride ourselves in delivering professional solutions to address the client's complex civil engineering needs and offer a range of end to end services that encompasses consultancy, design, health & safety, project management, delivery and construction. Terra Solutions has operated throughout the UK and Ireland with a range of key players in utility and infrastructure markets, helping to deliver key projects to ensure that essential services are maintained and improved. Our growth and stability over the last number of years is directly linked to the professionalism and integrity of our workforce along with the experience and knowledge of our management team who, for over thirty successful years in both utility and infrastructure sectors, have been providing ground-breaking solutions in a demanding world.


BACK TO TOP

Ward & Burke Construction Limited

Unit N, Bourne End Business Park
Coves End Road, Bourne End
Bucks SL8 5AS

Tel: 01494 775954
Mobile: 07540 221163
E-Mail:michael.ward@wardandburke.com
Website:www.wardandburke.com



Contact:Michael Ward

Ward & Burke Construction Ltd is a Civil Engineering Company based in the Republic of Ireland, The UK and Canada. It is an Engineer lead organization with direct labour and plant resources. It has extensive experience with pipelines, water retaining structures, bridges, and specialist no-dig solutions. Company owned equipment allows no-dig works including:

Micro-tunneling, Pipejacking, Auger-Boring, Pipe-ramming, Directional Drilling, Timber Headings and Shaft Construction. In-house design capabilities allow tunnels and shafts to be designed and detailed. The Company holds ISO9001, ISO14001 and OHSAS18001 certification as well as Professional Indemnity insurance for design.

The company specializes in long distance microtunnelling and large insitu caissons designed to water retaining standards. Shafts up to 30m deep by 20m internal diameter have been completed insitu as have slurry microtunnel drives up to 740m long with horizontal and vertical curves.

The company is familiar with structural and geotechnical design principles and can offer advice, structural analysis and cost estimates at early stages in project development. International experience has broadened the company's experience and has informed its approach to high risk work. Robust simplified methods can control project risk by avoidance; Ward and Burke offer their experience to all who seek the best engineering solution.


BACK TO TOP

Herrenknecht International Ltd

Wearfield, Sunderland
Tyne & Wear SR5 2TZ

Tel: 0191 548 9191
Fax: 0191 548 9292
E-Mail:enquiries@herrenknecht.co.uk
Website:www.herrenknecht.com



Contact:Roy Slocombe, Martin Soames

Herrenknecht International Limited is a subsidiary of Herrenknecht AG covering the UK and Ireland. Selling and marketing Herrenknecht tunnelling equipment and Bohrtec guided auger boring equipment, giving our customers the ability to successfully complete tunnels of all sizes.

Herrenknecht are world leaders in the manufacture of tunnelling equipment, designing and manufacturing a full range of modern tunnelling machines and back-up machinery for pipejack or segmentally lined tunnels. These include mixshield/slurry, earth pressure balance (EPB), excavator, roadheader, rock and auger boring.

Continual improvement in design and performance is the cornerstone of our philosophy. We can provide HDD equipment from 60 to 600 tonnes force, direct pipe equipment, vertical shaft sinking machines, and geothermal drilling rigs capable of depths to 5,000 metres.

From our large fleet of rental equipment we can provide equipment to offer our customers a total package for tunnel projects and pipejack.


BACK TO TOP

Iseki Microtunnelling

Airfield Road Hinwick,
Wellingborough, Northants NN29 7JQ

Tel: 01234 781166
Fax: 01234 781992
E-Mail:paul@isekimicro.com
Website:www.isekimicro.com



Contact:David Cook

Iseki Microtunnelling offers Microtunnelling Equipment for hire worldwide, and for over 29 years has been a sales distributor for Iseki Poly-Tech., Inc., the world leader in the field of remotely controlled Microtunnelling Shield Machines.

Iseki shields are supplied to install pipes from 250mm to 3500mm ID. Probably the best known Iseki machines are

• The Unclemole TCC which features a patented cone-crusher head with an with eccentric motion, well known for excellent performance in all soft ground conditions

• The Unclemole Super TCS, which adds hard rock-cutting to the Unclemole specification.

New advances include:

• The Iseki Shuttlemole, a retractable Microtunnelling machine for installing blind tunnels

• PLC Control System with Fibre Optic data transfer cable, which allows mass data transfer to the operation desk from multiple detectors in the MTBM and the tunnel.

• Iseki Data Recording, a software based system with facilities for remote diagnostics and automatic emailing of drive records. Supplied as standard with new PLC Control Systems and as transportable module for existing control systems

• A “bolt on” rock head for the Unclemole TCC MTBM, widening operational conditions to include medium rock, remarkable performance in coal measure / mudstone / shale / schist / siltstone ground conditions.

Iseki Microtunnelling operates one of the largest rental fleets in Europe, including both shield machines and backup equipment. To date more than 90km of installed tunnel has been completed in 25 countries. This experience allows Iseki Microtunnelling to offer expert project advice and end user support

In addition, Iseki Microtunnelling also offers a comprehensive maintenance and parts service, project-specific design capability, and the provision of experienced machine operators.


BACK TO TOP

FP McCann Ltd

Whitehill Road, Ellistown
Leicester LE67 1ET

Tel: 01530 240056
Fax: 01530 240015
E-Mail:scarson@fpmccann.co.uk
Website:www.fpmccann.co.uk



Contact:Stuart Carson (sales): 07850 234136

FP McCann Ltd is the UK's largest manufacturer of jacking and micro tunnelling pipes producing a complete range from 450mm to 2400mm ID in concrete.

The company prides itself on its customer focus and innovative approach using its expertise in design to solve customer's problems efficiently and economically.

McCann’s Easi- Lift system provides safe and efficient handling of jacking pipes without penetrating the inner wall of the pipe. This system is offered as standard on pipes from 900 mm.

All standard product pipes from diameters DN450 to DN 2400 incorporate a Lamell seal capable of maintaining an internal hydrostatic pressure of 35mm (3.5 bar) head of water.

For all enquiries please visit our website or contact Stuart Carson / the sales office.


BACK TO TOP

Naylor Drainage

Clough Green, Cawthorne
Barnsley, South Yorkshire S75 4AD

Tel: 01226 790591
Fax: 01226 791376
E-Mail:simon.marsh@naylor.co.uk
Website:www.naylor.co.uk



Contact:Simon Marsh

For a company with its origins in clay drainage pipes and over 100 years of experience in the manufacture of clay drainage pipes and fittings, it is natural that Naylor Drainage Ltd is at the forefront of product development and innovation.

With worldwide operational activities, Naylor Drainage is the world’s leading international supplier of specialist pipes for trenchless technology and many prestigious projects have been supplied both in the company’s domestic (UK) market and around the World.

Reputation for product reliability and customer service is all part of the Naylor experience.

The company’s trenchless technology product – Denlok – is a specially developed vitrified clay pipe system to meet the requirements of pipe installation by trenchless construction methods, which include:

Microtunnelling • Guided Auger Boring • Pipe Bursting • Pipe Eating • Slip Lining

The Naylor approach to its development of products for the trenchless construction industry has resulted in new manufacturing equipment and production techniques. These progressive steps have led to reductions in specialist product costs. These savings have been passed on to the customer to enable the use of a first-class product at affordable prices.


BACK TO TOP

Stanton Bonna Concrete Limited

Littlewell Lane, Stanton-by-Dale
Ilkeston, Derbyshire DE7 4QW

Tel: 0115 944 1448
Fax: 0115 944 1466
E-Mail:info@stanton-bonna.co.uk
Website:www.stanton-bonna.co.uk



Contact:David Williams

Stanton Bonna is part of the Consolis Group, Europe’s largest precast concrete producer, and is widely recognised as a leading UK manufacturer of precast concrete pipes and manholes as part of a comprehensive range of Drainage Systems, Pressure Systems, Railway Products and Specialist Precast solutions.

The company manufactures for the water, highways, rail, housing, telecom and power sectors of the construction industry.

Stanton Bonna has an excellent reputation for high standards in product quality and customer service. Their professional, helpful and friendly staff, meet the daily challenges of supplying the right product, to the right standard and to the right location reliably and promptly.

All Stanton Bonna Jacking Pipes are manufactured to BS 5911-1 and BS EN 1916 and available with a painted mild steel collar or stainless steel collar on request. The integrated elastomeric sealing gasket ensures a watertight joint. Interjack stations with integral ‘cans’ and ‘lead’ pipes are also available.

Products are manufactured in accordance with the relevant British and European standards and Kitemarked and/or CE Marked accordingly.

The company has also achieved a range of impressive accreditations including:

• Environmental Management System to BS EN ISO 14001

• Quality Assurance Scheme to BS EN ISO 9001

• UVDB Achilles

• Link-up Achilles

For up-to-date information, visit the Stanton Bonna website, where you can find product specifications, alongside case studies and the latest product news.


BACK TO TOP

COWI UK Limited (Consulting Engineers)

Eastfield, Church Street
Uttoxeter, Staffs ST14 5HU

Tel: 01889 563680
Fax: 01889 562586
E-Mail:info_uk@cowi.com
Website:www.cowiuk.com



Contact:Mr Damian McGirr

COWI UK Limited has over 30 years' experience providing consulting services to the tunnelling industry in:

New build tunnels • Railway tunnels • Pipejacks and Augerbores • Culverts • Timber headings • Temporary works • Inspection and assessments

From these roots the firm has expanded and developed complimentary skills and offers a comprehensive civil, structural and geotechnical design consultancy.

The firm has attracted staff with very wide ranging experience; this experience is the key to the services provided leading to much repeat work and our inclusion on tender lists against companies of greater size. We hav worked on tunnelling projects around the world in the design of large diameter tunnels for rail, road and power in both rock and soil in North America, Europe, Middle East, Australia and South East Asia.

COWI UK Limited has significant experience of pipejacked and augerbored tunnel design including many crossings below road, rail and river. We are familiar with all the various methods and machines utilised in construction and, crucially, have geotechnical experts who can advise on ground conditions and groundwater behaviour. Thus we not only provide designs, but also add value in terms of construction advice. We also have significant experience of gaining UK approvals from Network Rail, the Highways Agency and other permitting bodies.

The tunnelling design service we offer includes:

Feasibility & option studies • Site and ground investigation • Alignment design • Approval in Principal (AIP) • Permanent works design • Settlement analysis • Damage assessment • Risk assessment • Temporary works design • Tender design for contractors • Category III checks • Tender documentation for clients • Methodology, plant & equipment • Construction support • Expert witness

We have a reputation for being client focused and for solving geotechnically complex problems related to tunnelling. The firm has become highly respected by clients, contractors and other consultants in relation to the geotechnical and structural aspects of tunnelling processes.

The firm is represented on British Standards Institution and European Standards Institution (CEN) committees for the development of tunnelling safety standards and is represented on the committee of the British Tunnelling Society (an associated society of the Institution of Civil Engineers). Safety, quality and a care for the environment are built into our designs.

The company is accredited by NQA to:

BS EN ISO 9001:2008 Quality Management System

BS EN ISO 14001: 2004 Environmental Management System

NS OHSAS 18001:2007 Occupational Health & Safety Management System


BACK TO TOP

Tunnelling Accessories

Sidney Little Road, Churchfields Industrial Estate
St Leonards-on-Sea, East Sussex TN38 9PU

Tel: 01424 854112
Fax: 01424 854231
E-Mail:phil@tadrilling.co.uk
Website:www.tunnellingaccessories.co.uk



Contact:Philip Benford

With over 40 Years knowledge of the tunnelling Industry The TA Group aim to provide a fast and efficent one stop shop for all your tunneling goods & services requirements, supplying most items within 24/48 hours or same day if required.

Apart from the products of its own manufacture, Tunnelling Accessories stock many proprietary materials such as grummets, bolts, grout plugs, bitumen sealing packers, caulking compounds, leak sealers, hydrophilic rubber and small tools; the range is continually being extended and now includes products for use in the general construction industry. Tunnelling Accessories are also agents for overseas companies supplying specialised equipment and materials.

Other products available include joint packers, secondary seals, entry/exit seals and interjack seals for pipejacking projects and Bullflex a versatile shuttering system for TBM and shaft sinking projects, made of toughened geotextile.
